Boeing 727 vs 737
The Boeing 727 vs 737 are two types of airplanes, but they have some key differences. One major difference is their size and shape. The Boeing 727 is larger and has three engines, while the Boeing 737 is smaller and has two engines. Because of this, the 727 can carry more passengers and travel longer distances compared to the 737. Another difference is their design and purpose. The 727 was designed for longer flights, while the 737 was made for shorter trips. This means that the 727 is better suited for journeys that require more time in the air, while the 737 is ideal for shorter flights. These differences make each airplane unique and suitable for different kinds of travel needs. Check out our comparison Boeing 717 vs 737Â of the to see how they differ from each other.
Boeing 727-200ADV
The Boeing 727 was a popular passenger jetliner developed by Boeing Company. It was introduced in the 1960s and became well-known for its unique design and reliability. The plane had three engines and a sleek, narrow body, making it suitable for both short and long-distance flights. One of its standout features was its ability to operate on shorter runways compared to other aircraft of its time. The Boeing 727 quickly gained popularity among airlines worldwide for its efficiency and comfort. Throughout the 1970s and 1980s, it served as a workhorse for many airlines, carrying passengers to destinations across the globe. However, as newer, more fuel-efficient aircraft were introduced, the Boeing 727 gradually phased out of commercial service. Despite its retirement, the Boeing 727 remains an iconic symbol of aviation history and innovation.
Boeing 737
The Boeing 737 is a widely recognized and highly successful aircraft in commercial aviation. Introduced in the 1960s, it has become one of the most popular and versatile narrow-body jetliners worldwide. With its efficient design, the 737 is well-suited for short to medium-haul flights, making it a favorite among airlines for both domestic and international routes. Over the years, Boeing has introduced various variants of the 737, each offering improvements in range, capacity, and fuel efficiency. Its reliability, cost-effectiveness, and adaptability have made it a cornerstone of many airlines’ fleets. With millions of passengers flown safely each year, the Boeing 737 continues to play a significant role in modern air travel.
Boeing 727-200ADV vs Boeing 737-300
The Boeing 727 vs 737 have noticeable differences in various aspects. The 727-200ADV, being larger, boasts a longer length, greater wingspan, and higher wing area compared to the 737-300. Additionally, the 727-200ADV is equipped with three engines, whereas the 737-300 has two engines. Consequently, the total thrust of the 727-200ADV is higher than that of the 737-300. Moreover, the 727-200ADV has a significantly higher maximum take-off weight (MTOW) compared to the 737-300, allowing it to carry more payload. However, the 737-300 has a longer range and a slightly lower cruise speed compared to the 727-200ADV. These differences highlight the unique characteristics and capabilities of each aircraft, catering to different operational requirements and preferences.
| Attribute | Boeing 727-200ADV | Boeing 737-300 |
|---|---|---|
| Length | 46.69 m (153 ft 2 in) | 33.40 m (109 ft 7 in) |
| Wingspan | 32.91 m (108 ft) | 28.88 m (94 ft 9 in) |
| Wing Area | 157.90 m2 (1,700 ft2) | 105.40 m2 (1,135 ft2) |
| Height | 10.36 m (34 ft) | 11.13 m (36 ft 6 in) |
| Engines | 3 | 2 |
| Thrust per Engine | 77 kN (17,400 lbf) | 98 kN (22,000 lbf) |
| Total Thrust | 231 kN (52,200 lbf) | 196 kN (44,000 lbf) |
| MTOW | 95,000 kgs (209,000 lbs) | 62,800 kgs (138,000 lbs) |
| Range | 4,000 km (2,160 nm) | 5,000 km (2,700 nm) |
| Cruise Speed | Mach 0.76 | Mach 0.73 |
| Capacity | 148 passengers | 128 passengers |
Boeing 727-200ADV vs Boeing 737-400
The Boeing 727-200ADV vs Boeing 737-400 have notable differences in various aspects. The 727-200ADV is larger, with a longer length, greater wingspan, and higher wing area compared to the 737-400. Additionally, the 727-200ADV is equipped with three engines, whereas the 737-400 has two engines. Consequently, the total thrust of the 727-200ADV is higher than that of the 737-400. Moreover, the 727-200ADV has a significantly higher maximum take-off weight (MTOW) and can carry more passengers, with a capacity of 148 passengers compared to 146 passengers of the 737-400. However, the 737-400 has a slightly shorter range and lower cruise speed compared to the 727-200ADV. These differences make each aircraft suitable for different operational requirements and preferences.
| Attribute | Boeing 727-200ADV | Boeing 737-400 |
|---|---|---|
| Length | 46.69 m (153 ft 2 in) | 36.45 m (119 ft 7 in) |
| Wingspan | 32.91 m (108 ft) | 28.88 m (94 ft 9 in) |
| Wing Area | 157.90 m2 (1,700 ft2) | 105.40 m2 (1,135 ft2) |
| Height | 10.36 m (34 ft) | 11.13 m (36 ft 6 in) |
| Engines | 3 | 2 |
| Thrust per Engine | 77 kN (17,400 lbf) | 105 kN (23,500 lbf) |
| Total Thrust | 231 kN (52,200 lbf) | 210 kN (47,000 lbf) |
| MTOW | 95,000 kgs (209,000 lbs) | 68,000 kgs (150,000 lbs) |
| Range | 4,000 km (2,160 nm) | 3,850 km (2,079 nm) |
| Cruise Speed | Mach 0.76 | Mach 0.73 |
| Capacity | 148 passengers | 146 passengers |
Boeing 727-200ADV vs Boeing 737-500
The Boeing 727-200ADV vs Boeing 737-500 differ significantly in several aspects. Firstly, the 727-200ADV is larger in size, with a longer length, greater wingspan, and higher wing area compared to the 737-500. Additionally, the 727-200ADV is equipped with three engines, while the 737-500 has two engines. This difference in engine configuration affects the total thrust, with the 727-200ADV having a higher total thrust than the 737-500. Moreover, the 727-200ADV has a higher maximum take-off weight (MTOW) and can carry more passengers, with a capacity of 148 passengers compared to the 108 passengers of the 737-500. However, the 737-500 has a slightly longer range and a lower cruise speed compared to the 727-200ADV. These differences make each aircraft suitable for different operational needs and preferences.
| Attribute | Boeing 727-200ADV | Boeing 737-500 |
|---|---|---|
| Length | 46.69 m (153 ft 2 in) | 31.00 m (101 ft 8 in) |
| Wingspan | 32.91 m (108 ft) | 28.88 m (94 ft 9 in) |
| Wing Area | 157.90 m2 (1,700 ft2) | 105.40 m2 (1,135 ft2) |
| Height | 10.36 m (34 ft) | 11.13 m (36 ft 6 in) |
| Engines | 3 | 2 |
| Thrust per Engine | 77 kN (17,400 lbf) | 89 kN (20,000 lbf) |
| Total Thrust | 231 kN (52,200 lbf) | 178 kN (40,000 lbf) |
| MTOW | 95,000 kgs (209,000 lbs) | 60,000 kgs (132,000 lbs) |
| Range | 4,000 km (2,160 nm) | 4,444 km (2,400 nm) |
| Cruise Speed | Mach 0.76 | Mach 0.73 |
| Capacity | 148 passengers | 108 passengers |
Boeing 727-200ADV vs Boeing 737-600
When comparing the Boeing 727-200ADV vs Boeing 737-600, several significant differences become apparent. The Boeing 727-200ADV is longer and has a larger wingspan compared to the 737-600, providing more interior space. Additionally, the 727-200ADV is equipped with three engines, while the 737-600 has only two engines. Despite having fewer engines, the 737-600 has a higher thrust per engine, resulting in comparable total thrust between the two aircraft. However, the 727-200ADV has a significantly higher maximum take-off weight (MTOW) compared to the 737-600, allowing it to carry heavier loads. Moreover, the 737-600 has a shorter range and lower passenger capacity, accommodating only 108 passengers compared to the 148 passengers of the 727-200ADV. These differences in size, engine configuration, thrust, MTOW, range, and capacity make each aircraft suitable for different operational needs and preferences.
| Attribute | Boeing 727-200ADV | Boeing 737-600 |
|---|---|---|
| Length | 46.69 meters (153 ft 2 in) | 31.20 meters (102 ft 4 in) |
| Wingspan | 32.91 meters (108 ft) | 35.80 meters (117 ft 5 in) |
| Wing Area | 157.90 m2 (1,700 ft2) | 125.00 m2 (1,345 ft2) |
| Height | 10.36 meters (34 ft) | 12.60 meters (41 ft 4 in) |
| Engines | 3 | 2 |
| Thrust per Engine | 77 kN (17,400 lbf) | 101 kN (22,700 lbf) |
| Total Thrust | 231 kN (52,200 lbf) | 202 kN (45,400 lbf) |
| MTOW | 95,000 kgs (209,000 lbs) | 65,000 kgs (143,000 lbs) |
| Range | 4,000 km (2,160 nm) | 5,600 km (3,024 nm) |
| Cruise Speed | Mach 0.76 | Mach 0.785 |
| Capacity | 148 passengers | 108 passengers |
Boeing 727-200ADV vs Boeing 737Max 7
When comparing the Boeing 727-200ADV to the Boeing 737 MAX 7, several key differences emerge. The Boeing 727-200ADV is larger in terms of length and wingspan, boasting three engines compared to the two engines of the 737 MAX 7. This results in a higher total thrust for the 727-200ADV. However, despite its larger size and additional engine, the 737 MAX 7 has a longer range, allowing it to cover greater distances without refueling. Additionally, while both aircraft have similar cruising speeds, the 737 MAX 7 has a slightly higher passenger capacity, accommodating up to 153 passengers compared to the 148 passengers of the 727-200ADV. Overall, the choice between these aircraft depends on factors such as range requirements, passenger capacity needs, and operational preferences.
| Attribute | Boeing 727-200ADV | Boeing 737 MAX 7 |
|---|---|---|
| Length | 46.69 meters (153 ft 2 in) | 36.56 meters (119 ft 11 in) |
| Wingspan | 32.91 meters (108 ft) | 35.92 meters (117 ft 10 in) |
| Wing Area | 157.90 m2 (1,700 ft2) | 127.00 m2 (1,367 ft2) |
| Height | 10.36 meters (34 ft) | 12.30 meters (40 ft 4 in) |
| Engines | 3 | 2 |
| Thrust per Engine | 77 kN (17,400 lbf) | 119 kN (26,785 lbf) |
| Total Thrust | 231 kN (52,200 lbf) | 238 kN (53,570 lbf) |
| MTOW | 95,000 kgs (209,000 lbs) | 80,286 kgs (177,000 lbs) |
| Range | 4,000 km (2,160 nm) | 7,130 km (3,850 nm) |
| Cruise Speed | Mach 0.76 | Mach 0.79 |
| Capacity | 148 passengers | 153 passengers |
Boeing 727-200ADV vs Boeing 737 MAX 8
When comparing the Boeing 727-200ADV vs Boeing 737 MAX 8, several significant differences are apparent. The Boeing 727-200ADV is longer and has a greater wingspan compared to the 737 MAX 8, allowing for more space inside the aircraft. Additionally, the 727-200ADV is equipped with three engines, whereas the 737 MAX 8 has only two. This difference in engine configuration results in a higher total thrust for the 737 MAX 8. Despite having fewer engines, the 737 MAX 8 has a longer range, making it capable of covering greater distances without refueling. Furthermore, the 737 MAX 8 has a higher passenger capacity, accommodating up to 178 passengers compared to the 148 passengers of the 727-200ADV. Overall, the choice between these aircraft would depend on factors such as range requirements, passenger capacity needs, and operational preferences.
| Attribute | Boeing 727-200ADV1 | Boeing 737 MAX 8 |
|---|---|---|
| Length | 46.69 meters (153 ft 2 in) | 39.52 meters (129 ft 8 in) |
| Wingspan | 32.91 meters (108 ft) | 35.92 meters (117 ft 10 in) |
| Wing Area | 157.90 m2 (1,700 ft2) | 127.00 m2 (1,367 ft2) |
| Height | 10.36 meters (34 ft) | 12.30 meters (40 ft 4 in) |
| Engines | 3 | 2 |
| Thrust per Engine | 77 kN (17,400 lbf) | 125 kN (28,035 lbf) |
| Total Thrust | 231 kN (52,200 lbf) | 250 kN (56,070 lbf) |
| MTOW | 95,000 kgs (209,000 lbs) | 82,191 kgs (181,000 lbs) |
| Range | 4,000 km (2,160 nm) | 6,570 km (3,548 nm) |
| Cruise Speed | Mach 0.76 | Mach 0.79 |
| Capacity | 148 passengers | 178 passengers |
Boeing 727-200ADV vs Boeing 737 MAX 9
When comparing the Boeing 727-200ADV vs Boeing 737 MAX 9, there are notable differences between these two aircraft models. The Boeing 727-200ADV is longer and has a larger wingspan compared to the 737 MAX 9, offering more interior space. Additionally, the 727-200ADV is equipped with three engines, while the 737 MAX 9 has only two engines. Despite having fewer engines, the 737 MAX 9 boasts a higher total thrust, allowing for improved performance during flight. Furthermore, the 737 MAX 9 has a longer range and a higher passenger capacity, accommodating up to 193 passengers compared to the 148 passengers of the 727-200ADV. Overall, these differences in size, engine configuration, thrust, range, and capacity make each aircraft suitable for different operational needs and preferences.
| Attribute | Boeing 727-200ADV | Boeing 737 MAX 9 |
|---|---|---|
| Length | 46.69 meters (153 ft 2 in) | 42.16 meters (138 ft 4 in) |
| Wingspan | 32.91 meters (108 ft) | 35.92 meters (117 ft 10 in) |
| Wing Area | 157.90 m2 (1,700 ft2) | 127.00 m2 (1,367 ft2) |
| Height | 10.36 meters (34 ft) | 12.30 meters (40 ft 4 in) |
| Engines | 3 | 2 |
| Thrust per Engine | 77 kN (17,400 lbf) | 130 kN (29,317 lbf) |
| Total Thrust | 231 kN (52,200 lbf) | 260 kN (58,634 lbf) |
| MTOW | 95,000 kgs (209,000 lbs) | 88,314 kgs (195,000 lbs) |
| Range | 4,000 km (2,160 nm) | 6,570 km (3,548 nm) |
| Cruise Speed | Mach 0.76 | Mach 0.79 |
| Capacity | 148 passengers | 193 passengers |
Boeing 727-200ADV vs Boeing 737 MAX 10
Comparing the Boeing 727-200ADV vs Boeing 737 MAX 10 reveals several key differences between the two aircraft. The Boeing 727-200ADV, with its longer length and greater wingspan, offers more interior space than the 737 MAX 10. Additionally, the 727-200ADV is equipped with three engines, whereas the 737 MAX 10 has only two engines. Despite having fewer engines, the 737 MAX 10 boasts a higher total thrust, allowing for enhanced performance during flight. Moreover, the 737 MAX 10 has a longer range and a higher passenger capacity, accommodating up to 204 passengers compared to the 148 passengers of the 727-200ADV. These distinctions in size, engine configuration, thrust, range, and capacity contribute to different operational capabilities and suitability for various airline needs and preferences.
| Attribute | Boeing 727-200ADV | Boeing 737 MAX 10 |
|---|---|---|
| Length | 46.69 meters (153 ft 2 in) | 43.80 meters (143 ft 8 in) |
| Wingspan | 32.91 meters (108 ft) | 35.92 meters (117 ft 10 in) |
| Wing Area | 157.90 m2 (1,700 ft2) | 127.00 m2 (1,367 ft2) |
| Height | 10.36 meters (34 ft) | 12.30 meters (40 ft 4 in) |
| Engines | 3 | 2 |
| Thrust per Engine | 77 kN (17,400 lbf) | 130 kN (29,317 lbf) |
| Total Thrust | 231 kN (52,200 lbf) | 260 kN (58,634 lbf) |
| MTOW | 95,000 kgs (209,000 lbs) | 92,000 kgs (203,000 lbs) |
| Range | 4,000 km (2,160 nm) | 6,110 km (3,299 nm) |
| Cruise Speed | Mach 0.76 | Mach 0.79 |
| Capacity | 148 passengers | 204 passengers |
Conclusion
In conclusion, comparing the Boeing 717 vs 737 aircraft models reveals significant differences in various aspects such as size, capacity, range, and engine configuration. While both aircraft serve different niches within the aviation industry, understanding these distinctions is essential for airlines and passengers alike to make informed decisions based on their specific needs and preferences.
FaQs
What is the main difference between the Boeing 717 vs 737?
The main difference lies in their design and intended use. The Boeing 717 is a smaller, narrow-body aircraft primarily used for short-haul flights, while the Boeing 737 is a larger, more versatile aircraft suitable for both short and medium-haul routes.
Which aircraft has a higher seating capacity, the Boeing 717 or 737?
Typically, the Boeing 737 has a higher seating capacity compared to the Boeing 717. The 737 is available in various configurations, including models with larger seating capacities to accommodate more passengers.
What are the differences in range between the Boeing 717 vs 737?
The Boeing 737 generally has a longer range compared to the Boeing 717. This difference is due to the 737’s larger size and fuel capacity, allowing it to fly longer distances without the need for refueling.
How do the engine configurations differ between the Boeing 717 vs 737?
The Boeing 717 typically features two engines, while the 737 can have either two or four engines depending on the variant. The engine configuration affects factors such as fuel efficiency, thrust, and overall performance.
